| Product Name: QH-NV361-Megapixel IP Network camera |
|
1.0 Megapixel Array LED Dome IP Camera ,1/4" Progressive Scan CMOS ,H.264,Support Triple Streaming
|
 |
| |
|
FEATURE :
* H.264 Baseline:4.0, MPEG-4, M-JPEG, JPEG video encoding compression
* High-performance Build in 3A (AWB, AF, AE)
* Support 30 FPS @ 1280*720 resolution real-time encoding
* Can support multi-viewer to access concurrently
* Support triple encoding streams
* Support bi-directional and broadcasting real time audio transmission
* Support network self-adapting technology to adjust video frame rate automatically according to the network
* Bandwidth·Support privacy protection mode, motion detection and sensor alarm functions
* Auto-retrieve function and auto-connection network |
|
| |
|
Specification:
|
Model |
QH-NV361 |
|
Camera |
|
Sensor/DSP |
1/4" Progressive Scan CMOS |
|
Day/Night |
ICR |
|
Min. Illumination |
0.1lux @F1.2,AGC on,0 lux with IR on |
|
Lens |
4.3mm/6mm 3.0MP Fixed Lens |
|
IR LED |
1 Array LED |
|
IR Distance |
10~20m |
|
Electronic Shutter |
1/20~1/30000s |
|
Video |
|
Compression |
H.264/MPEG4/M-JPEG |
|
Max.image Resolution |
1280 x 720 |
|
Frame Rate |
30fps(1280 x 720) |
|
Bit Rate |
Stream 1: 1000~6000kps |
|
Stream 2: 512~2048kbps |
|
Stream 3: 64~256kbps |
|
Audio |
|
Compression |
G.711 |
|
Talkback |
YES |
|
Network |
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, FTP, UPNP |
|
Compliance |
ONVIF 2.1(1.02 backward compatible) |
|
PC Client and Browser |
ISS, IE6.0 and above |
|
Mobile phone |
Iphone, ipad, Android |
|
WIFI |
NA |
|
WIFI Encryption |
NA |
|
3G Network |
NA |
|
Interface |
|
Video Output |
NA |
|
Audio Input |
1 CH 3.5mm audio interface, MIC IN/LINE IN |
|
Audio Output |
1 CH 3.5mm audio interface |
|
Alarm Input |
NA |
|
Alarm Output |
NA |
|
LAN |
1 RJ45 10M / 100M ethernet port |
|
RS-485 |
1 |
|
Storage Interface |
Built-in micro sd slot, up to 32GB |
|
PIR |
NA |
|
General |
|
Working Temperature |
-10oC~ +55oC |
|
Working Humidity |
0% - 90% |
|
Protection Level |
/ |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
3.6W with IR ON ; 2.2W with IR OFF |
|
Dimensions |
138*138*67mm |
|
Weight |
800g |
|
|
| |
|
|
|
